Autonomous Object Retrieval Project

Welcome to the official documentation for our autonomous warehouse retrieval system. This project bridges advanced mobile navigation, robotic manipulation, and Vision-Language Models (VLMs) to create a fully autonomous robotic worker.

Platform Overview

The TurtleBot 4 is the next-generation ROS 2 educational and research robot. Built on the iRobot Create 3 mobile base, it features:

  • RPLidar A1M8: 2D laser scanner for SLAM and obstacle avoidance
  • OAK-D Pro: Spatial AI stereo camera for RGB-D perception
  • IMU & Wheel Encoders: For accurate odometry

Our project extends this platform with:

  • OpenManipulator-X: 4-DOF robotic arm for object manipulation
  • Google Gemini VLM: Vision-Language Model for intelligent object recognition

System Requirements

Component Version
Ubuntu 22.04 LTS
ROS 2 Humble Hawksbill
Python 3.10+
MoveIt 2 Humble
Gazebo Ignition Fortress

Mission Pipeline

Our project elevates the standard TurtleBot 4 by integrating it with an OpenManipulator-X robotic arm and the Google Gemini Vision-Language Model (VLM).

We have engineered an autonomous pipeline for object retrieval within a simulated warehouse environment. The system operates in the following sequence:

  1. Dispatch: User issues a retrieval command specifying the target zone.
  2. Transit: Robot navigates to the designated warehouse zone using Nav2.
  3. Search & Perception: Upon arrival, the perception system Gemini VLM or ArUco scan to identify and locate the target object.
  4. Alignment & Grasping: Visual servoing aligns the robot, then OpenManipulator-X picks the object.
  5. Return & Drop-off: Robot navigates home and deposits the item.

Project Demonstration

Watch the fully integrated system execute a retrieval mission:


System Architecture

System Architecture

System Requirements

This pipeline relies on the following core hardware and software components:

  • TurtleBot 4 Base (iRobot Create 3): Provides the mobile chassis, odometry, and low-level motor control.
  • RPLidar: A 2D laser scanner used for generating occupancy grids, localization (AMCL), and real-time obstacle avoidance.
  • OAK-D Pro Camera: Provides RGB and Depth streams for the perception pipeline and VLM integration.
  • OpenManipulator-X Arm: A 4-DOF robotic arm used for precision picking and placing.
  • ROS 2 & MoveIt 2: The underlying middleware and motion planning frameworks managing the entire ecosystem.

Quick Start Guide

1. Install Dependencies

Ensure your workspace is fully built and sourced before launching any nodes:

cd ~/workspace
rosdep install --from-paths src -y --ignore-src
colcon build
source install/setup.bash

2. Simulation Setup

Ensure your workspace is fully built and sourced before launching any nodes:

Terminal 1 - Gazebo Simulation:
ros2 launch tb4_openx_sim gazebo_sim.launch.py

*** Wait for all controllers to load

Terminal 2 - Navigation Stack:
ros2 launch tb4_openx_navigation navigate.launch.py

*** Open RViz, click "2D Pose Estimate" button, then click and drag on the map
to set the robot's initial position and orientation.

Terminal 3 - MoveIt 2:
ros2 launch tb4_openx_manipulation move_group.launch.py

Terminal 4 - Manipulation Pipeline:
ros2 launch tb4_openx_manipulation manipulation_pipeline.launch.py

Terminal 5 - Mission Controller:
ros2 run tb4_openx_navigation mission_controller.py

3. Real Robot Setup

Ensure your workspace is fully built and sourced before launching any nodes:

Terminal 1 - TurtleBot 4 Bringup (on robot):
ros2 launch turtlebot4_bringup standard.launch.py

*** Ensure the you saved your Map correct and all the ros2 topic from
TB4 is publishing on our PC

Terminal 2 - Navigation Stack:
ros2 launch tb4_openx_navigation real_navigate.launch.py

*** Make sure Map is loaded and everthing is loaded

Terminal 3 - MoveIt 2:
ros2 launch tb4_openx_manipulation move_group.launch.py use_sim:=false

Terminal 4 - Manipulation Pipeline:
ros2 launch tb4_openx_manipulation real_manipulation_pipeline.launch.py

Terminal 5 - Mission Controller:
ros2 run tb4_openx_navigation real_mission_controller.py

Authors

  • Dev Dipak Ghiya
  • Fazil Khan
  • Qingyuan Cao
